Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 425
CIP Objects Appendix A
AC Magnitude Detection Method
Peak Per Revolution Assessment
For active eccentricity application and assessment on a per revolution basis,
these attributes determine enable options and the low RPM limit where once
per revolution assessment defaults to normal peak-value assessment.
Lower RPM limit range: 4…600 RPM, recommended default of 10 RPM.
Value Description
0True peak
1 True peak to peak
2RMS
3 Rectified average
4Peak
5Scaled peak
6 Scaled peak to peak
Option Description
0x00 Peak per revolution disabled
0x01 Tacho/Speed 0
0x02 Tacho/Speed 01
Higher Values Reserved
Table 156 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x0E x x Get Attribute Single Returns the contents of the specified attribute
