Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 457
CIP Objects Appendix A
25 Get V Alarm Input 0 SINT Measurement Alarm
instance reference
that is used for input
0.
Range: 1…24
26 Get V Alarm Input 1 SINT Measurement Alarm
instance reference
that is used for input
1.
Range: 1…24
27 Get V Alarm Input 2 SINT Measurement Alarm
instance reference
that is used for input
2.
Range: 1…24
28 Get V Alarm Input 3 SINT Measurement Alarm
instance reference
that is used for input
3.
Range: 1…24
Alarm Multiplier Group of two configuration attributes.
32 Get V Alarm Multiplier
Control
BYTE Trigger Source and
Enable/Disable.
AM control options
33 Get V Alarm Multiplier ON
Time
DINT The time that the
alarm (threshold)
multiplier is applied
after the control is
toggled.
ms
Range: 0…65500
Speed Gating Group of four configuration attributes.
40 Get V Speed Gating Control SINT Speed gating data
source selection
with Enable/Disable
control.
Speed gating
sources
41 Get V Speed Gating
Detection
SINT Selection of
threshold or
window detection
methods.
Speed range
condition options
42 Get V Lower Speed
Threshold
REAL Low speed threshold
definition.
RPM
Range: 4…19000
43 Get V Higher Speed
Threshold
REAL High-speed
threshold definition.
RPM
Range: 5…20000
Logic Gating A configuration attribute.
48 Get V Logic Gating Source WORD Source definition for
the logic gating
trigger data,
including OFF
Logic gating source
options
Logic Control A configuration attribute.
56 Get V Logic Control
Source
WORD Source definition for
the logic control
trigger data
Refer logic gating
source options but
note that only one
logic control source
is allowed.
Table 188 - Instance Attributes (continued)
