46 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 2 Install the Dynamix 1444 Series Monitoring System
Use these switches for automatic configuration or definition of the last octet of
a static (Class C) IP address.
To adjust the rotary switches, use a small screwdriver.
Setting Description
000 Automatic address assignment (default)
001…254 Static IP address setting (for example, 192.168.1.xxx
255…887 Automatic address assignment
888 Out-of-box reset
When set, after power-up, the module immediately executes an out-of-box reset. See
Resetting the Module
on page 241 for further information.
889…999 Automatic address assignment
