Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 461
CIP Objects Appendix A
Speed Gating Source
Following sources can be identified as the source of the speed gating.
0x00 defines Speed gating is disabled, multiple sources not allowed.
Speed Range Condition
Defines speed-range assessment type.
Table 195 - Speed Gating Source
Value Description
o OFF
1 Tacho/Speed 0
2 Tacho/Speed 1
3 Factored speed from Tacho 0
4 Factored speed from Tacho 1
Higher Values Reserved
Speed Range Condition
Value Description
0x00 (0) - High-Level Greater than high range
0x01 (1) - Low Level Lower than low range
0x02 (2) - In Window Within defined low and high range
0x03 (3) - Out Window Outside defined low and high range
