Appendix A CIP Objects
Enable
A bit-wise enable control, per instance/channel.
Waveform averaging is only a valid selection when waveform is enabled, the
Advanced CM data source is set to the Alternate path and is configured for
synchronous sample generation. Refer also the Channel Set Up Object.
FFT Averaging is only a valid selection when FFT is enabled. If the FFT,
Wav e f o rm , Wav e f o rm Ave r a g i n g , a n d F F T Av er a g i n g b i ts a r e a l l s e t , Wa v e f or m
Averaging is not performed while the other selections are performed.
It is possible to specify both FFT and Waveform for a channel. Waveform,
Waveform Averaging, and FFT is also a valid combination. FFT, Waveform,
and FFT Averaging is also a valid combination.
Table 228 - Enable
Value Description
0 FFT
1 Waveform
2 Waveform Averaging
3 FFT Averaging
4…7 Reserved
