Allen-Bradley 1444-TSCX02-02RB User Manual

Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 493
CIP Objects Appendix A
Table 243 - Instance Attributes
Attribute
ID
Access Rule NV Name Data Type Description of
Attribute
Semantics of
Values
- - - Read Time Slot
Configuration
-- -
1 Get V Time slot channel
enables
WORD Bit-wise channel
enables for time
slots 0 to 3
All 16 bits used
2 Get V Time slot 0 DAQ
time
REAL Time slot 0
minimum DAQ
time
s
3 Get V Time slot 1 DAQ
time
REAL Time slot 1
minimum DAQ
time
s
4 Get V Time slot 2 DAQ
time
REAL Time slot 2
minimum DAQ
time
s
5 Get V Time slot 3 DAQ
time
REAL Time slot 3
minimum DAQ
time
s
6 Get V Time slot 0
Settling time
REAL Time slot 0
Settling time
s
7 Get V Time slot 1
Settling time
REAL Time slot 1
Settling time
s
8 Get V Time slot 2
Settling time
REAL Time slot 2
Settling time
s
9 Get V Time slot 3
Settling time
REAL Time slot 3
Settling time
s
-- -Time Slot
Configuration
-Group of 4
configuration
attributes
-
16 Get V Time Slot 0 DAQ
time Multiplier
INT Time Slot 0 DAQ
time Multiplier
Default value: 1
Range: 1...255
17 Get V Time Slot 1 DAQ
time Multiplier
INT Time Slot 1 DAQ
time Multiplier
Default value: 1
Range: 1...255
18 Get V Time Slot 2 DAQ
time Multiplier
INT Time Slot 2 DAQ
time Multiplier
Default value: 1
Range: 1...255
19 Get V Time Slot 3 DAQ
time Multiplier
INT Time Slot 3 DAQ
time Multiplier
Default value: 1
Range: 1...255
