Appendix A CIP Objects
NV status relates to nonvolatile storage in the auxiliary module, not the main
module.
Module address is fixed, as is the link between instances and current outputs.
Table 254 - Instance Attributes
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
1 Get V Current Output Value REAL Provides processed current output value in
mA
2 Get V Source Measurement Value REAL Provides actual measurement value in
engineering units
General Group of 3 configuration attributes.
16 Get V Current Output Enable SINT Current output enable control. 0: Not enabled
1: Enabled
17 Get V Current Output
Measurement Identifier
INT Defines source of 4…20 mA signal Source selection
18 Get V Current Output Name SINT[32] A name to identify this output instance 32 characters
Output Scaling Group of 3 configuration attributes.
19 Get V 20 mA Output Scaling REAL Definition of measurement value that is
associated with 20 mA.
Range: -40000…50000
20 Get V 4 mA Output Scaling REAL Definition of measurement value that is
associated with 4 mA.
Range: -50000…40000
Default: 0
24 Get V Current Output Not OK
Configuration
SINT The current output set when a fail
condition is detected (TX Fail of associated
channel, auxiliary bus failure, auxiliary
module self-check fail)
Not OK configuration
