Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 507
CIP Objects Appendix A
20 Get NV NetX Firmware Build SHORT-STRING Build Date (ASCII string) for example, length 0x0B 56, 65, 70,
20, 31, 37
Sep 17
20, 32, 30, 31, 34
2014
21 Get NV DSP Firmware Build UDINT Build Version for example, 10034 is V1.00.34
22 Get - DSP Configuration CRC UINT 16-bit CRC for the DSP and
Auxiliary relevant
configuration
Is unchanged if configuration
changes are limited to CM features
23 Get - NetX/DSP Error Status DWORD DSP: bits 0...15 NetX: bits
16...31
Normal (no error) status = 0
Bit 0 - DSP Not responding
Bit 1 - DSP in boot loader mode
Bit 2 - Configuration process failed
to complete
Bit 16 - Corrupt object file detected
Main Module Tacho A configuration attribute.
24 Get V Tacho Mode SINT Individual or Redundant
Mode
0: Individual
else Redundant Tacho Mode
Main Module Opto Outputs 0/1 A group of two configuration attributes.
32 Get V Opto Output 0 Allocation SINT Source configuration for
this Opto-isolated output.
Opto source
33 Get V Opto Output 1 Allocation SINT Source configuration for
this Opto-isolated output.
Opto source
Main Module Local Onboard Relay A logical grouping of parameters.
39 Get V Auto Local Relay Control BYTE Configuration of local relay
behavior in case of
detected fault condition,
which is based on
associated voted alarm.
Returns 0 if relay source is not a
voted alarm
Relay control
40 Get NV User Local Relay Control BYTE User configuration of local
relay behavior in case of
detected fault condition.
Relay control
41 Get NV Local Relay Control BYTE Actual behavior of local
relay in case of detected
fault condition.
Relay control
42 Get V Relay Source SINT Link to corresponding
voted alarm object
(instance and output
type).
Relay source decoding
43 Get V Relay Drive Test Enable BOOL Whether the relay drive
circuit is being routinely
tested.
Automatic on fail-safe setting
44 Get V Relay Drive Test
Interval
UINT Test interval. ms
64 Get V Redundant Power Supply SINT Whether the module is
being powered
redundantly.
0: Not redundant
1: Redundant
Channel 0 DSP FFT Group of seven configuration attributes.
72 Get V Enable SINT An enable control. Only
enable if FFT bands are
required from this channel.
0: Disable
1: Enable
73 Get V Signal Source SINT Defines the data source. Source
Table 258 - Class Attributes (continued)
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
