514 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Measurement Units
Actual selection of Measurement engineering units are a subset of the master
engineering units list. It is based on active measurement application for the
applicable measurement channel (related to sensor type and signal processing).
Index FFT Resolution
0x04 (4) 1600 lines
Index FFT Window
0x00 (0) Normal/Rectangular
0x01 (1) Flat Top
0x02 (2) Hanning
0x03 (3) Hamming
Index Number of Averages
0x00 (0) 1
0x01 (1) 2
0x02 (2) 3
0x03 (3) 6
0x04 (4) 12
0x05 (5) 23
0x06 (6) 45
0x07 (7) 89
0x08 (8) 178
Table 263 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x0E x x Get Attribute Single Returns the contents of the specified attribute
Table 264 - Object Specific Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x4B x x Set Module Time Allows a module time date to be set (in the
absence of a system time from the network).
Data: UINT32 - seconds since 1970 UINT32 -
nanoseconds
