524 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Table 279 - Analog Output Module / Tacho Signal Conditioner Status
Bit Description (Analog Output Module) Bit Description (Tacho Signal Conditioner)
0 Analog output module not responding. If set
disregard other bits in this group.
16 Tacho signal conditioner module not
responding. If set disregard other bits in this
group.
1 Module is configured (so normally expected
set).
17 Module is configured (so normally expected
set).
2 Code CRC fault. 18 Code CRC fault.
3 High temperature warning. 19 High temperature warning.
4 Link/bus fail. 20 Link/bus fail.
5 Halt is active. 21 Halt is active.
6 RAM fault. 22 RAM fault.
7 RAM access error. 23 RAM access error.
8 Channel 0 not inhibited (so normally set). 24 Spare
9 Channel 1 not inhibited. 25
10 Channel 2 not inhibited. 26 Speed 0 Estimated.
11 Channel 3 not inhibited. 27 Speed 1 Estimated.
12 Spare 28 +25V5 supply fail.
13 29 -25V5 supply fail.
14 30 Tacho 0 sensor fault.
15 31 Tacho 1 sensor fault.
