CIP Objects Appendix A
Output Assembly
The output assembly includes a fixed 2 integer “Control” tag, of which only the
first integer is used. Optionally, the Control Tag may be followed by 2, 16 or 18
REALs.
Table 282 - Output Control Tag
Table 283 - Output Speed Tag (Optional)
Bit Description Bit Description
0 Trip (alarm) Inhibit (Bypass). 16 Spare
1 Set Point Multiplier Enable 0. 17
2 Set Point Multiplier Enable 1. 18
3 Speed0 ok status. 19
4 Speed1 ok status. 20
5 Gate0 control. 21
6 Gate1 control. 22
7Alarm reset. 23
8 Alarm buffer trigger. 24
9 Alarm buffer reset. 25
10 Transient buffer0 reset. 26
11 Transient buffer1 reset. 27
12 Transient buffer2 reset. 28
13 Transient buffer3 reset. 29
14 Maximum speed measurement reset (all
speeds).
30
15 Spare 31
Notes
If any of the expansion relay modules are not present, their control and indication can be configured and
used as virtual relays.
REAL Description
0 Speed 0
1 Speed 1
Note
The speed tag is an optional array "Speed[2]" of two RPM values that the module can use as input to
either of its speed measurements. The tag is included in the output when specified in Module
Definition.
