530 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Attribute Semantics
State
0 - Nonexistent
1 - No file loaded
2 - Fled loaded
3 - Transfer Upload Initiated
4 - Transfer Download Initiated
5 - Transfer Upload in Progress
6 - Transfer Download in Progress
7 - Storing
8...255 - Reserved
Table 288 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x0E x x Get Attribute Single Returns the contents of the
specified attribute
Table 289 - Object Specific Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x4B - x Initiate Upload Start a file upload
0x4F - x Upload Transfer Performs a file transfer upload
