Appendix A CIP Objects
Table 308 - Instance Attributes
Attribute
ID
Access
Rule
NV Name Data Type Description of Attribute Semantics of
Values
1 Get Interface Speed UDINT 0x64
(100 Mbps)
2 Get Interface Flags DWORD
3 Get Physical Address STRUCT Array of 6 USINT values MAC ID
4 Get Interface Counters STRUCT Array of 11 UDINT values
5 Get Media Counters STRUCT Array of 12 UDINT values
6 Get/Set Interface Control STRUCT Two control bits are supported:
Bit 0: Set for (802.3) auto negotiated enabled
Bit 1 - Forced duplex mode, set for full-duplex (only applicable with
autonegotiation disabled.
If auto-negotiate is disabled, the Forced Interface Speed parameter indicates the
speed at which the interface operates in megabits per second.
Examples for 10 mpbs the value is 10.
9 Get/Set Administrative State Enable/disable 1: Enable
2: Disable
10 Get Interface Label SHORT_STRING port 1/port 2
Table 309 - Common Services
Service
Code
Implementation Service Name
Class Instance
0x0E x x Get Attribute Single
0x10 - x Set Attribute Single
