78 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 2 Install the Dynamix 1444 Series Monitoring System
Upper Module Connector
Terminal 18 17 16 15 14 13
Name REL 2 NC REL 2 COM REL 2 NO REL 3 NC REL 3 COM REL 3 NO
Application Relay 2 Relay 3
Description
Normally closed
Common
Normally open
Normally closed
Common
Normally open
1444-RELX00-04RB Relay Expansion Module
and 1444-TB-B Terminal Base
Lower Module Connector
Te rm in a l 1 2 3 4 5 6
Name REL 0 NC REL 0 COM REL 0 NO REL 1 NC REL 1 COM REL 1 NO
Application Relay 0 Relay 1
Description
Normally closed
Common
Normally open
Normally closed
Common
Normally open
Lower Base Connector
Te rm in a l 7 8 9 1 0 11 12
Name SH SH NOT USED SH SH
Application Shield Shield
Description
Cable shield connection points
Do not connect
Cable shield connection points
To Next Page
