80 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 2 Install the Dynamix 1444 Series Monitoring System
Use of the same power supply that serves the Dynamix module to power other
devices is allowed if it can serve the additional loads. However, when powering
multiple devices it is important to make sure that the supply can serve the
startup surge currents of the device. The startup surge currents can be greater
than their normal operating load requirements. If the supply isn’t adequate
during startup of another device, it could affect current provided for Loop
Power. As a result, there can be unexpected changes in the measured current
levels on the system.
Upper Base Connector
Terminal 24 23 22 21 20 19
Name NOT USED SH SH SH SH NOT USED
Application Shield
Description
Do not connect
Cable shield connection points
Do not connect
Upper Module Connector
Terminal 18 17 16 15 14 13
Name OUTPUT 2 HI OUTPUT 2 LO NOT USED NOT USED OUTPUT 3 HI OUTPUT 3 LO
Application 4…20 mA Output 2 4…20 mA Output 3
Description
High
Low
Do not connect
High
Low
1444-AOFX00-04RB Analog Output Expansion Module
and 1444-TB-B Terminal Base
