Rockwell Automation Publication 1734-UM001E-EN-P - July 2013
168 Default Data Maps
1734-IV2 Source Input Module
Message Size: 1 Byte
1734-IV4 Source Input Module
Message Size: 1 Byte
1734-IV8 Source Input Module
Message Size: 1 Byte
76543210
Produces (scanner Rx) Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = input channel 0 data Ch 1 = input channel 1 data
76543210
Produces (scanner Rx) Ch3 Ch1 Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = input channel 0 Ch 1 = input channel 1 Ch 2 = input channel 2 Ch 3 =
input channel 3
76543210
Produces (scanner Rx) Ch7 Ch6 Ch5 Ch4 Ch3 Ch1 Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = input channel 0 Ch 1 = input channel 1 Ch 2 = input channel 2 Ch 3 = input channel
3 Ch 4 = input channel 4 Ch 5 = input channel 5
Ch 6 = input channel 6 Ch 7 = input channel 7
