Install POINT I/O Modules 47
Wire the Communication Interface Module for AC Modules Only
1734-FPD Field Potential Distributor Module
01 01 01
120V AC
PDN OW2OW2
AC Power Bus
C
V
NC
C
V
NC
NC = No Connection
CHAS GND = Chassis Ground
C = Common V = Supply
CHAS GND
CHAS GND
