Publication 1734-UM006B-EN-P - August 2005
2-10 Install the Module
Module Configuration
Parameter Set/Get Description Bytes
1 Set/Get Counter Configuration 1
2 Set/Get Filter Selection 1
3 Set/Get Decimal Position 1
4 Set/Get Reserved 1
5 Set/Get Time Base Value 2
6 Set/Get Gate Interval 1
7 Set/Get Channel Scalar 1
8 Set/Get Channel Rollover Value 4
9 Set/Get Channel Preset Value 4
10 Set/Get Counter Control Safe State 1
11 Set/Get Requested Poll Produce Assembly 1
12 Set/Get Requested Change of State Produce Assembly 1
Counter Configuration
07 06 05 04 03 02 01 00
ZI MD CF Counter 0
0 0 0 0 Counter
0 0 0 1 Encoder X1
0 0 1 0 Encoder X2
0 0 1 1 Not used
0 1 0 0 Encoder X4
0 1 0 1 Period/Rate
0 1 1 0 Not used
0 1 1 1 Rate Measurement
0 0 0 Store Count Disabled
0 0 1 Mode 1 - store-continue
0 1 0 Mode 2 - store-wait-resume
0 1 1 Mode 3 - store, reset-wait-start
1 0 0 Mode 4 - store, reset-start
101 Reserved
110 Reserved
111 Reserved
0 Z input - 0 = not inverted
1 Z input - 1 = inverted
