Publication 1734-UM006B-EN-P - August 2005
4-4 Configure Your Module
Set Counter Parameters
After adding the module to the network, you must configure the
modules for use.
1. Configure the modules as shown below.
You will see a pop-up dialog with a series of tabs. Each tab provides
options view or edit.
Refer to the dialogs for an explanation of its features.
IMPORTANT
This chapter shows configuration in the online
mode. Changes set in this mode take effect when
you download to the individual module.
1. Right-click on the module.
2. Click on Properties to
configure your adapter.
You can also left click on the module or name
and the property dialog will pop up.
These are the tabs you click on to
view the options.
To Next Page
