Publication 1734-UM006B-EN-P - August 2005
Configure Your Module 4-5
The module’s name appears
here.
Type a description here.
The module’s address appears
here. (This field is read only.)
This dialog also shows the
module’s device identity.
These fields are read-only.
At any point, you can click here to finish
changing configuration parameters.
IMPORTANT: If configuration changes ar
made in offline mode, they
do not take effect until the
system goes online.
Click on the Device parameters tab
to get to the dialog for setting the
parameters.
This dialog appears after clicking on
the Device parameters tab. If you
want the existing parameters
uploaded from the module, select
Upload. The following dialog will
then show the existing parameters
set on the module.
Use this pulldown menu to
edit or view the parameters.
Available choices are:
PointBus
Status
Configuration
AB Drives
To Next Page
