Allen-Bradley 1734-IK User Manual

Publication 1734-UM006B-EN-P - August 2005
Input and Output Data 3-5
Counter Configuration (Configuration Word 1)
Use this byte to select the type of counter desired.
Filter Selection (Configuration Word 2
This byte sets the A/B/Z input filters
Filter Selection
07 06 05 04 03 02 01 00
ZI MD CF Counter 0
0000Counter
0001Encoder X1
0010Encoder X2
0011Reserved
0100Encoder X4
0101Period/Rate
0110Reserved
0111Rate Measurement
0 0 0 Store Count Disabled
0 0 1 Mode 1 - store/continue
0 1 0 Mode 2 - store/wait/resume
0 1 1 Mode 3 - store, reset/wait/start
1 0 0 Mode 4 - store, reset/start
101 Reserved
110 Reserved
111 Reserved
0 Z input - 0 = not inverted
1 Z input - 1 = inverted
07 06 05 04 03 02 01 00
0ZFBFAF FS
0000No Filter
000150kHz (10µs + 0µs/-1.6µs)
00105kHz (100µs + 0µs/-13.2µs)
0100500Hz (1.0ms + 0µs/-125µs)
100050Hz (10ms + 0ms/-1.25ms)
0 A input not filtered
1 A input filtered
0 B input not filtered
1 B input filtered
0 Z input not filtered
1 Z input filtered
