Publication 1794-6.5.8 - January 2010
106 Input, Output, Status and Configuration Files for Analog Modules when used with ControlNet
Word 2 Channel Configuration
Bits 00-03 Channel 0 Configuration
Bits 04-07 Channel 1 Configuration
Bits 08-11
(10-13)
Channel 2 Configuration
Bits 12-15
(14-17)
Channel 3 Configuration
Word 3 Bits 00-14
(00-16)
Real Time Sample Interval – Programs the interval of the real time sample. Can be
varied from 0 to 30 seconds (30000 decimal). Resolution is in ms with granularity in 5ms
steps.
Bit 15 (17) Not used. Set to 0.
Table 6.3
Word/Bit Descriptions for Isolated Analog Input Module
Word Decimal Bit
(Octal Bit)
Definition
