Allen-Bradley 1794-IF4I - Features of Your Analog Modules; Summary

Publication 1794-6.5.8 - January 2010
14 Overview of FLEX I/O and your Analog Modules
Features of Your Analog
Modules
Each module has a unique label identifying its keyswitch position,
wiring and module type. A removable label provides space for writing
individual designations per your application.
Summary
In this chapter you learned about the FLEX I/O system and the types
of analog modules and how they communicate with programmable
controllers.
Removable
Label
Input Designators
Output Designators
Keyswitch
Position
Indicator (#3)
1794-IF4I
1794-OF4I
Keyswitch
Position
Indicator (#4)
Module Type
Module Type
Removable
Label
Module Type
Keyswitch
Position
Indicator (#5)
Green Power/Status
Indicator
Green Power/Status
Indicator
Input and Output Designators
1794-IF2XOF2I
Green Power/Status
Indicator
Removable
Label
