Allen-Bradley 1794-IF4I - Filter Response for 150 Hz, 300 Hz and 600 Hz Conversion

Publication 1794-6.5.8 - January 2010
134 Specifications
Filter Response for 150Hz, 300Hz and 600Hz Conversion
Figure A.1
Filter Response at 150Hz Conversion
±100
±90
±80
±70
±60
±50
±40
±30
±20
±10
0
5
15 25 35 45 55 65 75 85 95
105 115 125 135 145 155 165 175 185 195
Frequency [Hz]
Magnitude [dB]
