Publication 1794-6.5.8 - January 2010
Writing Configuration to and Reading Status from Your Module with a Remote I/O Adapter 57
can be set individually. Select the filter based on your system require-
ments.
Reading Data From Your
Module
Read programming moves status and data from the module to the
processor’s data table. The processor’s user program initiates the
request to transfer data from the input module (or combination
module) to the processor.
Mapping Data for the
Analog Modules
The following read and write words and bit/word descriptions
describe the information written to and read from the analog modules.
Each word is composed of 16 bits.
A/D Conversion Rate Low Pass Filter
1200Hz No low pass
1200Hz 100ms low pass
1200Hz 500ms low pass
1200Hz 1000ms low pass
600Hz No low pass
600Hz 100ms low pass
600Hz 500ms low pass
600Hz 1000ms low pass
300Hz No low pass
300Hz 100ms low pass
300Hz 500ms low pass
300Hz 1000ms low pass
150Hz No low pass
150Hz 100ms low pass
150Hz 500ms low pass
150Hz 1000ms low pass
To Next Page
