Publication 1794-6.5.8 - January 2010
16 How to Install Your Analog Module
Low Voltage Directive
This product is tested to meet Council Directive 2006/95/EC Low
Voltage, by applying the safety requirements of EN 61131–2
Programmable Controllers, Part 2 – Equipment Requirements and
Tests.
For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as the following Allen-Bradley
publications:
• Industrial Automation Wiring and Grounding Guidelines For
Noise Immunity, publication 1770-4.1
• Guidelines for Handling Lithium Batteries, publication AG-5.4
• Automation Systems Catalog, publication B111
Open style devices must be provided with environmental and safety
protection by proper mounting in enclosures designed for specific
application conditions. See NEMA Standards publication 250 and IEC
publication 529, as applicable, for explanations of the degrees of
protection provided by different types of enclosure.
Power Requirements
The wiring of the terminal base unit is determined by the current draw
through the terminal base. Make certain that the current draw does
not exceed 10A.
ATTENTION
Total current draw through the terminal base unit is
limited to 10A. Separate power connections may be
necessary.
