Module Tag Definitions Appendix B
Output Tags
Table 73 describes the 5069-IB6F-3W module output tags.
Table 73 - 5069-IB6F-3W Module Output Tags
Name Size Definition Valid Values
Counterxx.Reset BOOL When this bit transitions from 0 to 1, I:Count, and
I:Rollover are set to zero.
• 0 = Do not reset
• 1 = Reset
Counterxx.RolloverAck BOOL Clears the Rollunder bit in the input tag when it
transitions from 0 to 1.
0 or 1
Counterxx.Preset DINT • If RolloverAtPreset is set, the counter counts to the
Preset value and then rolls over to zero.
• If RolloverAtPreset is not set, the counter sets the Done
bit and continues counting up to Max DINT.
• If C:RolloverAtPreset = 1, then if I:Count ≥ O:Preset,
I:Count=0. I:Done bit always = 0. Set I:Rollover bit
when I:Count transitions from O:Preset – 1 to 0.
• If C:RolloverAtPreset = 0, then if I:Count ≥ O:Preset,
I:Done = 1, else I:Done = 0. Set I:Rollover bit when
I:Count transitions from 2,147,483,647 to 0.
0…2,147,483,647
Ptxx.ResetTimestamps BOOL Erases all recorded timestamps for the input channel
when it transitions from 0 to 1.
• 0 = Timestamps are not erased
• 1 = Timestamps are erased
Ptxx.TimestampOffOnNumberAck INT An Off to On timestamp identifier that is written by the
controller to indicate that the identified timestamp has
been seen and acted on. When Latching is enabled and
the Timestamp Number that is received from the
controller matches the most recent timestamp that is
produced, the module can produce a new timestamp.
IMPORTANT: When this tag value matches the
Ptxx.TimestampOffOnNumber input tag value the
Pt.xxTimestampOffOn input tag value is cleared.
All values.
Ptxx.TimestampOnOffNumberAck INT An On to Off timestamp identifier that is written by the
controller to indicate that the identified timestamp has
been seen and acted on. When Latching is enabled and
the Timestamp Number that is received from the
controller matches the most recent timestamp that is
produced, the module can produce a new timestamp.
IMPORTANT: When this tag value matches the
Ptxx.TimestampOnOffNumber input tag value, the
Pt.xxTimestampOnOff input tag value is cleared.
All values.
