Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 87

Input Module Features Chapter 3

Module Health Diagnostic

Every Compact 5000 I/O digital module has a status indicator on the front of

the module that indicates module health.

For more information on status indicators, see Appendix A,

Troubleshoot Your

Module on page 211.
