Chapter 4 Output Module Features
Compact 5000 I/O Safety Output Modules
Table 39 lists tags that are used on Compact 5000 I/O safety output modules.
For more information on fault reporting, see Appendix A,
Troubleshoot Your
Module on page 211.
IMPORTANT For more information on the valid values for each tag in Table 39, see
Appendix B,
Module Tag Definitions on page 231.
Table 39 - Compact 5000 I/O Safety Output Modules - Fault and Data Status
Data Type Tag Name Triggering Event That Sets
Fault
ConnectionFaulted
(1)
The owner-controller loses its connection to the module.
Ptxx.Fault The point data quality is bad or the channel is set to Not Used.
Ptxx.ShortCircuit A short circuit condition exists on the point.
Ptxx.FieldPowerOff A field power lost condition exists on the point.
Status
RunMode The module is in Run Mode.
DiagnosticActive Indicates if any diagnostics are active or if the prognostics threshold is
reached.
DiagnosticSequenceCount The count increments each time that a diagnostic condition is detected
or removed.
Ptxx.Readback A 24V DC power source is connected to the output circuit.
Ptxx.Data The data currently at the point.
Ptxx.Uncertain The point data can be imperfect.
(1) This tag provides module-wide data an affects all channels simultaneously.
