Allen-Bradley 5069-OBV8S User Manual

146 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Chapter 5 Safety Module Features
Single-channel Mode
When the output channel is in the On state and without any faults, the safety
outputs turned on. The status is normal. If a fault is detected on the output
channel, the safety output data and individual safety output status turn off.
For information on how to use single-channel mode with a 5069-OBV8S or
5069-OBV8SK module affects the safety application suitability level, see
Table 44 on page 143.
Figure 19 - 5069-OBV8S or 5069-OBV8SK Single-channel Mode (Not to Scale)
Normal Operation
Fault Detection
ON
OFF
ON
OFF
ON
OFF
ON
OFF
Safety Output 0
Status
Output 0
Safety Network Data
Sent to the Controller
Safety Output 0
Status
Output 0
Safety Network Data
Sent to the Controller
Error Detected
