254 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Appendix B Module Tag Definitions
Ptxx.Chatter BOOL 1 = the Shows that the input is chattering per the
ChatterTime and ChatterCount settings. 0 = Normal
• 0 = Normal
• 1 = Input is chattering
Ptxx.TimestampOverflowOnOff BOOL Indicates an On to Off time stamp was lost in a discrete
product. If TimestampLatchEn is set, a new time stamp
was not recorded because one is already latched. If
TimestampLatchEn is clear, a timestamp was overwritten.
0 or 1
Ptxx.TimestampOverflowOffOn BOOL Indicates an Off to On time stamp was lost in a discrete
product. If TimestampLatchEn is set, a new time stamp
was not recorded because one is already latched. If
TimestampLatchEn is clear a timestamp was overwritten.
0 or 1
Ptxx.CIPSyncValid BOOL Indicates whether the module is synced with a 1588
master.
• 0 = CIP Sync is not available
• 1 = CIP Sync is available
Ptxx.CIPSyncTimeout BOOL Indicates that the module was once synced with a 1588
master, but is not now due to a timeout.
• 0 = A valid time master has not timed out.
• 1 = A valid time master was detected on the
backplane, but the time master has timed out.
The module is using its local clock and can be
drifting away from the last known time
master.
Ptxx.TimestampOffOnNumber INT A timestamp number for the Off to On transition for the
most-recently produced timestamp.
IMPORTANT: If Timestamp Latching is enabled, when this
tag value matches the Ptxx.TimestampOffOnNumberAck
output tag value, the Pt.xxTimestampOffOn input tag
remains the same until the next input Off to On transition.
Otherwise, the input tag value is cleared.
All values.
Ptxx.TimestampOnOffNumber INT A timestamp number for the On to Off transition for the
most-recently produced timestamp.
IMPORTANT: If Timestamp Latching is enabled, when this
tag value matches the Ptxx.TimestampOnOffNumberAck
output tag value, the Pt.xxTimestampOnOff input tag
remains the same until the next input On to Off transition.
Otherwise, the input tag value is cleared.
All values.
Ptxx.TimestampOffOn LINT 64-bit Timestamp corresponding to when a change of
state Off to On was recorded at the input.
IMPORTANT: This number is cleared when
Pt.xx.TimestampOffOnNumber input tag value and the
Ptxx.TimestampOffOnNumberAck output tag value
match.
All values.
Ptxx.TimestampOnOff LINT 64-bit Timestamp corresponding to when a change of
state On to Off was recorded at the input.
IMPORTANT: This number is cleared when
Pt.xx.TimestampOnOffNumber input tag value and the
Ptxx.TimestampOnOffNumberAck output tag value
match.
All values.
Table 72 - 5069-IB6F-3W Module Input Tags
Name Size Definition Valid Values
