Rockwell Automation Publication 825-UM004D-EN-P - November 2012 175
ASCII Serial Communications Chapter 12
Table 105 - STATUS Command Report and Definitions
STATUS Report
Designator
Definition Message Format
FID Firmware identifier string (FID string)
CID Firmware checksum identifier xxxx
Identity Code Relay configuration identification Identity string
Current Offset
(L1, L2, L3, RES, CB)
DC offset in hardware circuits of current channels OK/WARN
Voltage Offset
(VA, VB, VC)
DC offset in hardware circuits of voltage channels OK/WARN
PS_Vdc Power supply status OK/FAIL
FPGA FPGA programming unsuccessful, or FPGA failed OK/FAIL
GPSB General Purpose Serial Bus OK/FAIL
HMI
front panel FGPA programming unsuccessful, or front panel
FPGA failed
OK/WARN
RAM Volatile memory integrity OK/FAIL
ROM Firmware integrity OK/FAIL
CR_RAM Integrity of settings in RAM and code that runs in RAM OK/FAIL
Non_Vol
Integrity of data stored in nonvolatile
memory
OK/FAIL
Clk_Bat Clock battery integrity OK/WARN
Clock Clock functionality OK/WARN
PTC Integrity of PTC OK/FAIL
RTD Integrity of RTD module/communications OK/FAIL
MCM/CWE Integrity of current board and MCM/CWE OK/FAIL
Voltage Integrity of voltage board OK/FAIL
I/O_Crd Integrity of I/O card OK/FAIL
COM_Crd Integrity of DeviceNet card and network OK/FAIL
MAC ID DeviceNet card specific card identification. xxxxxx
ASA Manufacturer identifier for DeviceNet. xxxx xxxxx
DN_Rate DeviceNet card network communications data speed ___ kbps
DN_Status DeviceNet connection and fault status. 000b bbbb
