Chapter 12 ASCII Serial Communications
Figure 58 - STATUS Command - Example
Figure 59 - Identity Code Explanation
Figure 60 - DN_Status Explanation
=>>STA
825-P Modular Date: 03/03/2003 Time: 11:54:40.361
Prot. System
FID=825-P-R100-V0-Z001001-D20030225 CID=010C
Identity Code 1522001BCX0X1X1X
SELF TESTS
Current L1 L2 L3 RES CB
Offset: OK OK OK OK OK
Voltage VA VB VC
Offset: OK OK OK
PS_Vdc FPGA GPSB HMI
OK OK Ok Ok
RAM ROM CR_RAM Non_Vol Clk_Bat Clock
OK OK OK OK Ok OK
PTC RTD MCM/CWE Voltage I/O_Crd Com_Crd
OK Ok OK OK OK OK
MAC_ID ASA DN_Rate DN_Status
0 0000 0000h 0kbps 0000 0000
Relay Enabled
=>>
1 5 5 2 0 0 1 B A X O X O A O X
Voltage Sensing Card
0 None
1 Installed
Expansion I/O Card
0 None
1 Installed
Communication Card
0 None
3 DeviceNet
Converter Module
X None
A 825-MCM2
B 825-MCM5
C 825-MCM20
D 825-MCM180
E 825-MCM420
F 825-MCM630N
Undefined
I/D Idle
I/O Fault
Explicit Fault
I/O Connection
Explicit Connection
0 0 0 0
0 0 0 0
