248 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter E DeviceNet Information
Instance 103 is the 825 Current Input (produced) assembly.
Instance 104 is the 825 Misc. Input (produced) assembly.
This is a “Read Only” status assembly.
This is a “Read Only” status assembly.
Instance 103 825 Current
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Warning Tripped
1% Thermal Capacity Used
2 Average 3 Phase Current (low)
3 Average 3 Phase Current (high)
4 % Asymmetry
Instance 104 825 Phase Current
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Warning Tripped
1% Thermal Capacity Used
2 Average 3 Phase Current (low)
3 Average 3 Phase Current (high)
4 % Asymmetry
5 Max value of all Temperature sensors
6 Earth Current (low)
7 Earth Current (high)
Instance 180 Hardware Inputs 1-6
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
1
Instance 184 Produced Network Outputs 1-15
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Net Out 8 Net Out 7 Net Out 6 Net Out 5 Net Out 4 Net Out 3 Net Out 2 Net Out 1
1 Net Out 16 Net Out 15 Net Out 14 Net Out 13 Net Out 12 Net Out 11 Net Out 10 Net Out 9
