Allen-Bradley 825-P User Manual

Rockwell Automation Publication 825-UM004D-EN-P - April 2012 249
DeviceNet Information Chapter E
This is a “Read Only” status assembly.
This is a “Read Only” status assembly.
This is a “Read Only” status assembly.
This is a “Read Only” status assembly.
This is a “Read Only” status assembly.
Instance 185 Trip Status 1
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 GF Res PTC RTD Wind Short Ckt Cur Imbal Jam Undercurrent Overload
1 GF CB Sp Switch P Factor Ph Rev Over V Under V Under power VAR
Instance 186 Trip Status 2
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 MCM err RTD err PTC err RTD Amb RTD other Freq 2 Freq 1 Stall
1 Remote Comm Idle Comm Loss
Instance 187 Warning Status 1
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 GF Res PTC RTD Wind Short Ckt Cur Imbal Jam Undercurrent Overload
1 GF CB Sp Switch P Factor Ph Rev Over V Under V Under power VAR
Instance 188 Warning Status 2
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 MCM err RTD err PTC err RTD Amb RTD other Freq 2 Freq 1 Stall
1 Remote Comm Idle Comm Loss
Instance 189 Module Status
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 I/O Idle I/O Flt Exp Flt I/O Cnxn Exp Cnxn
1 Warning Trip
