96 Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 6 Configuring Protection & Logic Functions
The 825-P allows mapping of protection trip elements to the trip output.
Table 42 shows the method of mapping elements using Relay Word bits
associated with elements. Select 1 for each element you want to map using the
TRIPA through TRIPD settings. The relay will OR them together to drive the
Trip output. A logical “OR” describes when any one assigned element asserts,
the Trip relay will operate.
Auxiliary I/O
Table 43 - Aux Assignments
Setting Prompt 01234567Description
Aux# A X Overload
X Undercurrent
XJam
X Current Imbalance
XShort Circuit
X RTD (Winding/Bearing)
XPTC
X Ground Fault (Residual)
Aux# B X VAR
XUnderpower
XUndervoltage
XOvervoltage
X Phase Reversal
X Power Factor
XSpeed Switch
X Ground Fault (Core Balance)
Aux# C X Start Time
XFrequency 1
XFrequency 2
XRTD (Other)
X RTD (Ambient)
XPTC Error
XRTD Error
XMCM Error
