Rockwell Automation Publication 825-UM004D-EN-P - November 2012 97

Configuring Protection & Logic Functions Chapter 6

Aux# D X Comm Idle

XComm Loss

X Remote Trip

X Comm Fault

XLatch Trip

XReserved

Aux# E X Overload Warning

X Undercurrent Warning

XJam Warning

XCurrent Imbalance Warning

X RTD (Winding/Bearing) Warning

X Power Factor Warning

X Ground Fault (Core Balance) Warning

X Ground Fault (Residual) Warning

Aux# F X VAR Warning

X Underpower Warning

X Undervoltage Warning

XOvervoltage Warning

XSpeed Switch Warning

XFrequency 1 Warning

XFrequency 2 Warning

XRTD (Other) Warning

Aux# G X RTD (Ambient) Warning

XSetting Warning

X General Warning

X Load Control — Upper

X Load Control — Lower

XTimer 1

XTimer 2

XShort Circuit Warning

Table 43 - Aux Assignments

Setting Prompt 01234567Description
