Configure and Start the Kinetix 5700 Drive System Chapter 6
Table 103 - Navigating the Regenerative Bus Supply Menu
Menu/Sub Menu
Selections
Attributes Description Example Values
Module Info
Catalog number 2198-RPxxx
Firmware revision FW REV: 10.1.10500409
Hardware revision HW REV: 2.1
Serial number SERIAL#: xxxxxxxxxxx
Diagnostics>
Converter
Diagnostics
Converter diagnostics
CONV UTIL: 0.7%
CONV TEMP: 31.7C
SHUNT UTIL: 0.0%
DC BUS: 0.0V
IBUS: 0.0A
CONV UTIL: 0.0%
CONV TEMP: 22.6C
PWR OUT: 0.0kW
IGND:0.0A RMS
AC FREQ: 0.1Hz
IL1: 0.0A RMS
IL2: 0.0A RMS
IL3: 0.0A RMS
VL1-2: 0.0V RMS
VL2-3: 0.0V RMS
VL3-1: 0.0V RMS
VL1-N: 0.0V RMS
VL2-N: 0.0V RMS
VL3-N: 0.0V RMS
VBUS REF: 690V
SYNC STS: 0
ACT PWR: 0.0kW
PF: 0.0
VAC UNBAL: 0.0%
IAC UNBAL: 0.0%
PHASE SEQ: 0.0
Digital Inputs
IN1: OFF
IN2: OFF
IN3: OFF
IN4: OFF
Digital Outputs
CONT ENABLE: 0
PWR SUP OK: 0
Fault Log
Fault text Fault code as listed in Fault Codes
on page 277. FLT S23 – AC PHASE LOSS
Fault details The problem as reported in Fault Codes
on page277
One AC phase has been lost on the AC line to the
converter.
Fault help The Possible Solution as reported in Fault Codes
on page 277. Check AC input voltage on all phases.
