Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 193
Configure and Start the Kinetix 5700 Drive System Chapter 6
Table 105 - Navigating the Inverter Settings Menu
Settings Menu Selections Sub Menu Selections Attributes Default Description
Protected Mode
Reset
ENABLED
DISABLED
ENABLED
When Enabled (default), identity object or
safety resets are not possible when a
controller connection is open.
Network Config
ENABLED
DISABLED
ENABLED
When Enabled (default), network
configuration changes are not possible when
a controller connection is open.
Flash Update
ENABLED
DISABLED
ENABLED
When Enabled (default), firmware updates
are not possible when a controller
connection is open.
Device Config
ENABLED
DISABLED
ENABLED
When Enabled (default), only attribute
writes are possible when a controller
connection is open.
Network
->Static IP
(1)
IP address 192.168.1.1 Indicates current IP address
Subnet mask 255.255.255.000 Indicates current subnet mask
Gateway 192.168.001.001 Indicates current gateway
DHCP
On Turns DHCP on
Off Turns DHCP off
Display
Backlight Timeout
30 sec…NEVER
(NEVER=no timeout period,
the backlight is always on)
-> 3 min
(1)
Sets backlight timeout period of the display
Cyclic Data Select
(2)
->DC BUS
(1)
DC bus voltage
INV UTIL Inverter utilization in percent
INV TEMP Inverter temperature in °C
MOTOR UTIL Motor utilization in percent
SPEED RPM
OUT PWR Output power in watts
OUT FREQ Output frequency in hertz
OUT CUR Output current in amps
Set Contrast -10…+10 0 Contrast setting of the display
Safety Reset Ownership Are you sure?
Resets safety ownership
(reset fails after 30 seconds)
Web
Enabled Enables the web server
->Disabled Disables the web server
(1) An arrow (->) appears in front of the chosen attribute indicating that this attribute is currently configured. This is also the factory default setting.
(2) The DC bus voltage is one of several cyclic data attributes. You can select any of the Cyclic Data Select attributes to be displayed on the Home screen.
