38 Rockwell Automation Publication 2198-UM002G-EN-P - February 2019
Chapter 1 Start
Table 7 - Shared-bus Connector Kit Catalog Numbers
Shared-bus Connector Kits
Cat. No.
Drive Module
Cat. No.
Application Description
2198-TCON-24VDCIN36
(1)
(2)
2198-P031, 2198-P070, 2198-P141, 2198-P208
2198-CAPMOD-2240
24V DC input power to control bus 24V DC input wiring connector2198-RP088, 2198-RP200, 2198-DCBUSCOND-RP312
2198T-W25K-P-IN
(1)
(2)
2198T-W25K-ER, 2198-RP263, 2198-RP312,
2198-S263-ERSx, 2198-S312-ERSx
2198-H040-P-T
2198-D006-ERSx, 2198-D012-ERSx
2198-D020-ERSx, 2198-D032-ERSx
2198-CAPMOD-2240, 2198-DCBUSCOND-RP312
Control power sharing Control power T-connector with bus bars, 55 mm
2198-H070-P-T 2198-D057-ERSx, 2198-S086-ERSx, 2198-S130-ERSx Control power sharing Control power T-connector with bus bars, 85 mm
2198-S160-P-T 2198-S160-ERSx
Control power sharing Control power T-connector with bus bars, 100 mm
2198T-W25K-P-T 2198T-W25K-ER
2198-S312-P-T 2198-S263-ERSx, 2198-S312-ERSx Control power sharing Control power T-connector with bus bars, 220 mm
(1) The input wiring connector can be inserted into any drive module (mid-stream in the drive system) to begin a new 24V control bus when the maximum current value is reached. However, the input
connector must always extend the 24V DC-bus from left to right. The 2198T-W25K-P-IN male plug is physically larger than the male plug on 2198-TCON-24VDCIN36.
(2) For drive module amp ratings and connector wire size information, see Control Power
on page 113, and CP Connector Plug Wiring Specifications table on page 146, respectively.
