Allen-Bradley Kinetix 6200 User Manual

Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 251
Interconnect Diagrams Appendix A
Figure 111 - AM Module with LDC-Series Linear Motors
(flying-lead cables)
W
V
U
GND
4
3
2
1
W
V
U
GREEN/YELLOW
BLACK
WHITE
RED
BLACK
BLACK
RED
WHITE
BLUE
ORANGE
BLACK
W
V
U
TS+
TS-
POWER
S1
S2
S3
COM
SIN+
SIN-
COS+
COS-
IM+
IM-
POWER
COM
TS+
S1
S2
S3
13
8
12
11
(AM+)
(AM-)
(BM+)
(BM-)
1
2
3
4
5
10
14
6
SIN+
SIN-
COS+
COS-
IM+
IM-
POWER
COM
(AM+)
(AM-)
(BM+)
(BM-)
Motor Power
(MP) Connector
Cable Shield
Clamp
Note 10
Note 15
LDC-Cxxxxxx-xHTx1
Linear Motor Coil with
Sin/Cos or TTL External Encoder
and Flying-lead Cables
Three-phase
Motor Power
Motor Feedback
(MF) Connector
Thermostat
Grounding Technique for
Feedback Cable Shield
Turn clamp over to hold
small cables secure.
Exposed shield secured
under clamp.
Clamp Screws (2)
Clamp
Refer to table on page 232
for note information.
IAM (inverter) or AM
Power Module
External
Sin/Cos or (TTL)
Encoder
Kinetix 6200 or Kinetix 6500
Control Module
Hall Effect
Module
Wire as shown using
cable type appropriate for
your application.
2090-K6CK-D15M
Low-profile Connector Kit
2090-K6CK-D15M
Connector Kit
Refer to Low Profile Connector Kit Installation Instructions,
publication 2094-IN007
, for connector kit specifications.
