Appendix G
RBM Module Interconnect Diagrams
This appendix provides Bulletin 2090 Resistive Brake Module (RBM)
interconnect diagrams specific to Kinetix 6200 and Kinetix 6500 modular
servo-drive systems.
Before You Begin
These procedures assume you have installed your RBM module with the
Kinetix 6200 or Kinetix 6500 servo-drive system. For RBM module
installation instructions, refer to the Resistive Brake Module Installation
Instructions, publication 2090-IN009
.
For Kinetix 6200 drive systems, you can set the delay time for your RBM
module in the Logix Designer application. Refer to Configure Axis Properties
on page 157
.
For Kinetix 6500 drive systems, you can set the delay time for your RBM
module in the Logix Designer application. Refer to Configure Axis Properties
on page 184
.
Topic Page
Before You Begin 313
RBM Module Wiring Examples 314
ATTENTION: Use the interconnection diagrams as a general
recommendation of how the control circuit can be implemented. Actual
applications can vary due to requirements based on the machine builders
risk assessment. The machine builder must perform a risk assessment and
determine a category level of safety that must be applied to the machine.
