Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 27
Chapter 2
Plan the Kinetix 6200 and Kinetix 6500 Drive
System Installation
This chapter describes system installation guidelines used in preparation for
mounting your Kinetix 6200 and Kinetix 6500 drive components.
Topic Page
System Design Guidelines 28
Electrical Noise Reduction 36
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful to
keep any metal debris from falling into it. Metal debris or other foreign
matter can become lodged in the circuitry, which can result in damage to
components.
