Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017 23
Overview Chapter 1
1250 Model
2711P-RDK12C Keypad 12.1-in. color
2711P-RDK12CK Keypad •
2711P-RDT12C Touch
2711P-RDT12CK Touch •
2711P-RDT12H
(1)
Keypad/Touch
2711P-RDT12AG Touch •
2711P-RDB12C Keypad/Touch
2711P-RDB12CK Keypad/Touch •
1500 Model
2711P-RDK15C Keypad 15-in. color
2711P-RDT15C Touch
2711P-RDT15AG Touch •
2711P-RDB15C Keypad/Touch
(1) H at end of cat. no. refers to 1250 High-bright display module.
Table 15 - Display Modules - 700 to 1500 Terminals
Cat. No. Input Type Display Marine
Certified
Conformal
Coated
Built-in
Antiglare Overlay
Table 16 - Logic Modules - 700 to 1500 Terminals
Cat. No.
Power
Input
Memory
RAM/Nonvolatile
Communication
Marine
Certified
Conformal
Coated
Included Software
Without Standard Features
2711P-RP8A AC
512 MB/512 MB
(approximately 79 MB
free user memory)
• Ethernet
• RS-232
• Network interface for
communication module
••Windows CE 6.0 operating system
• FactoryTalk View Machine Edition runtime,
version 6.0 or later
• FactoryTalk ViewPoint software,
version 1.2 or later
2711P-RP8D DC •
2711P-RP8DK DC ••
With Extended Features
2711P-RP9A AC
512 MB/512 MB
(approximately 79 MB
free user memory)
• Ethernet
• RS-232
• Network interface
communication module
••Windows CE 6.0 operating system
with extended features and file viewers
• FactoryTalk View Machine Edition runtime,
version 6.0 or later
• FactoryTalk ViewPoint software,
version 1.2 or later
2711P-RP9D DC •
2711P-RP9DK DC ••
Table 17 - Communication Modules - 700 to 1500 Terminals
Cat. No.
Communication
Conformal
Coated
Marine
Certified
Ethernet DH+ DH-485 ControlNet
(2)
(2) Scheduled and unscheduled communication.
2711P-RN6 ••
2711P-RN6K •• •
2711P-RN15S ••
2711P-RN15SK ••
2711P-RN20
(1)
(1) All terminals have an Ethernet port. The cat. no. 2711P-RN20 module provides an additional Ethernet port.
•
