Allen-Bradley PanelView Plus 6 User Manual

22 Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017
Chapter 1 Overview
Accessories
Tables 15…28 list accessories for the PanelView Plus 6 terminals.
Table 14 - PanelView Plus 6 - 700 to 1500 Terminals with Extended Features
Cat. No. Display Communication
Input
Power
Memory (MB)
(1)
Keypad Touch Keypad/Touch Size Type RS-232 Ethernet RAM Nonvolatile
700 Model
2711P-K7C4D9 2711P-T7C4D9 2711P-B7C4D9 6.5-in. Color ••DC
512
512
(approx. 79 MB
free user memory)
2711P-K7C4A9 2711P-T7C4A9 2711P-B7C4A9 ••AC
1000 Model
2711P-K10C4D9 2711P-T10C4D9 2711P-B10C4D9 10.4-in Color ••DC
512
512
(approx. 79 MB
free user memory)
2711P-K10C4A9 2711P-T10C4A9 2711P-B10C4A9 ••AC
1250 Model
2711P-K12C4D9 2711P-T12C4D9 2711P-B12C4D9 12.1-in Color ••DC
512
512
(approx. 79 MB
free user memory)
2711P-K12C4A9 2711P-T12C4A9 2711P-B12C4A9 ••AC
1500 Model
2711P-K15C4D9 2711P-T15C4D9 2711P-B15C4D9 15-in. Color ••DC
512
512
(approx. 79 MB
free user memory)
2711P-K15C4A9 2711P-T15C4A9 2711P-B15C4A9 ••AC
(1) The logic module supports FactoryTalk View Machine Edition software, version 6.0 or later, FactoryTalk ViewPoint software version 1.2 or later, and the Windows CE 6.0 operating system with extended
features and file viewers.
Table 15 - Display Modules - 700 to 1500 Terminals
Cat. No. Input Type Display Marine
Certified
Conformal
Coated
Built-in
Antiglare Overlay
700 Model
2711P-RDK7C Keypad 7-in. color
2711P-RDK7CK Keypad •
2711P-RDT7C Touch
2711P-RDT7CK Touch •
2711P-RDT7CM Touch •
2711P-RDB7C Keypad/Touch
2711P-RDB7CK Keypad/Touch •
2711P-RDB7CM Keypad/Touch •
1000 Model
2711P-RDK10C Keypad 10-4 in. color
2711P-RDT10C Touch
2711P-RDT10CM Touch •
2711P-RDB10C Keypad/Touch
2711P-RDB10CM Keypad/Touch •
