Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017 119
Chapter 5
Install and Replace Components
Required Tools
You need a #1 and #2 Phillips screwdriver to replace some of the components.
Topic Page
Install or Replace the Logic Module 120
Install or Replace a Communication Module 121
Replace the Display Module 123
Replace the Bezel 124
Replace the Backlight 126
Replace the Battery 130
Install the AC Power Supply Module 132
Remove the Product ID Label 134
Replace the Keypad Legend Inserts 134
Load an SD Card 136
Clean the Display 137
ATTENTION: Prevent Electrostatic Discharge
This equipment is sensitive to electrostatic discharge, which can cause internal
damage and affect normal operation.
Follow these guidelines when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• Use a static-safe workstation, if available.
• Store the equipment in appropriate static-safe packaging when not in use.
ATTENTION: Shock Hazard
Disconnect power from the terminal before installing or replacing any
components. Failure to disconnect power can result in electrical shock or damage
to the terminal.
