Allen-Bradley PanelView Plus 6 User Manual

20 Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017
Chapter 1 Overview
400/600 Terminal Selections
The table shows the catalog number breakdown for the 400 and 600 terminals.
Bulletin Input Type Display Size Display Type Communication Power Operating System
|| || | | |
2711P- K = Keypad 4= 3.5 in. C = Color 5 = RS-232, USB A = AC 8 = Windows CE 6.0
B = Keypad and Touch 6 = 5.7 in. M = Grayscale 20 = Ethernet, RS-232, USB D = DC 9 = Windows CE 6.0 with extended features
T = Touch
Table 10 - PanelView Plus 6 - 400 Terminals without Extended Features
Cat. Nos. Display Communication Ports USB Ports
Input
Power
Memory (MB)
(1)
Keypad Keypad and Touch Size Type RS-232 Ethernet Host Device RAM Nonvolatile
2711P-K4M5A8 — 3.5-in. Grayscale • • • AC
256
512
(approx. 73 MB
free user memory)
2711P-K4M5D8 — • • • DC
2711P-K4M20A8 — • • • • AC
2711P-K4M20D8 — • • • • DC
2711P-K4C5A8 2711P-B4C5A8 3.5-in. Color • • • AC
2711P-K4C5D8 2711P-B4C5D8 • • • DC
2711P-K4C20A8 2711P-B4C20A8 • • • • AC
2711P-K4C20D8 2711P-B4C20D8 • • • • DC
(1) The terminal s support FactoryTalk View Machine Edition software, version 6.10 or later, and the Windows CE 6.0 operating system.
Table 11 - PanelView Plus 6 - 600 Terminals without Extended Features
Cat. Nos. Display Communication Ports USB Ports
Input
Power
Memory (MB)
(1)
Keypad Touch Keypad and Touch Size Type RS-232 Ethernet Host Device RAM Nonvolatile
2711P-K6M5A8 2711P-T6M5A8 2711P-B6M5A8 5.7-in. Grayscale • • • AC
256
512
(approx. 73 MB
free user memory)
2711P-K6M5D8 2711P-T6M5D8 2711P-B6M5D8 • • • DC
2711P-K6M20A8 2711P-T6M20A8 2711P-B6M20A8 • • • • AC
2711P-K6M20D8 2711P-T6M20D8 2711P-B6M20D8 • • • • DC
2711P-K6C5A8 2711P-T6C5A8 2711P-B6C5A8 5.7-in. Color • • • AC
2711P-K6C5D8 2711P-T6C5D8 2711P-B6C5D8 • • • DC
2711P-K6C20A8 2711P-T6C20A8 2711P-B6C20A8 • • • • AC
2711P-K6C20D8 2711P-T6C20D8 2711P-B6C20D8 • • • • DC
(1) The terminals support FactoryTalk View Machine Edition software, version 6.10 or later, and the Windows CE 6.0 operating system.
Table 12 - PanelView Plus 6 - 600 Terminals with Extended Features
Cat. Nos. Display Communication USB Ports
Input
Power
Memory (MB)
(1)
Keypad Touch Keypad and Touch Size Type RS-232 Ethernet Host Device RAM Nonvolatile
2711P-K6C5A9 2711P-T6C5A9 2711P-B6C5A9 5.7-in. Color • • • AC
256
512
(approx. 73 MB
free user memory)
2711P-K6C5D9 2711P-T6C5D9 2711P-B6C5D9 • • • DC
2711P-K6C20A9 2711P-T6C20A9 2711P-B6C20A9 • • • • AC
2711P-K6C20D9 2711P-T6C20D9 2711P-B6C20D9 • • • • DC
(1) The terminals support FactoryTalk View Machine Edition software, version 6.10 or later, and the Windows CE 6.0 operating system with extended features and file viewers.
