Chapter 2 Install Terminal
Mounting Clearances
Plan for adequate space around the terminal, inside the enclosure, for ventilation
and connections. Consider heat produced by other devices in the enclosure. The
ambient temperature around the terminal must be 0…55 °C (32…131 °F).
A clearance of 102 mm (4 in.) is sufficient on the side of the terminal to insert
and remove an SD card, and on the bottom of terminal for connections.
Panel Guidelines
The terminals are panel-mounted devices intended to mount in the door or wall
of a NEMA rated, UL Type rated, or IP rated enclosure:
• Supporting panels must have a mounting thickness of 1.5…4.8 mm
(0.060…0.188 in.).
• The material strength and stiffness of the panel must be sufficient to hold
the terminal and maintain an appropriate seal against water and dust.
• The panel surface must be flat and free of imperfections to maintain an
adequate seal and NEMA and UL Type ratings.
Panel Cutout Dimensions
Use the full size template shipped with your terminal to mark the panel cutout
dimensions.
Table 31 - Minimum Required Clearances
Product Area Minimum Clearance
Top 51 mm (2 in.)
Bottom 102 mm (4 in.)
Side 25 mm (1 in.)
Back 0 mm (0 in.)
Table 32 - Panel Cutout Dimensions
Terminal Input Type Height, mm (in.) Width, mm (in.)
400 Keypad or keypad/touch 123 (4.86) 156 (6.15)
600
Keypad or keypad/touch 142 (5.61) 241 (9.50)
Touch 123 (4.86) 156 (6.15)
700
Keypad or keypad/touch 167 (6.57) 264 (10.39)
Touch 154 (6.08) 220 (8.67)
1000
Keypad or keypad/touch 224 (8.8) 375 (14.75)
Touch 224 (8.8) 305 (12.00)
1250
Keypad or keypad/touch 257 (10.11) 390 (15.35)
To uc h
(1)
(1) Also applies to high-bright display module, cat. no. 2711P-RDT12H.
257 (10.11) 338 (13.29)
1500
Keypad or keypad/touch 305 (12.00) 419 (16.50)
Touch 305 (12.00) 391 (15.40)
