Overview Chapter 1
700 to 1500 Terminal
Selections
The table shows the catalog number breakdown for the 700 to 1500 terminals.
Bulletin Input Type Display Size Display Type Communication
(1)
Power Operating System Special Option
|| || | | | |
2711P- K = Keypad 7 = 6.5 in. C = Color 4 = Ethernet, RS-232 & (2) USB A = AC 8= Windows CE 6.0 K = Conformal-Coated
T = Touch 10 = 10.4 in. D = DC 9 = Windows CE 6.0 with
extended features
B = Keypad/Touch 12 = 12.1 in.
15 = 15 in.
(1) Optional communication modules are available as separate catalog numbers.
Table 13 - PanelView Plus 6 - 700 to 1500 Terminals without Extended Features
Cat. No. Display Communication
Input
Power
Memory (MB)
(1)
Keypad Touch Keypad/Touch Size Type RS-232 Ethernet RAM Nonvolatile
700 Model
2711P-K7C4D8 2711P-T7C4D8 2711P-B7C4D8 6.5-in. Color ••DC
512
512
(approx. 79 MB
free user memory)
– 2711P-T7C4D8K – ••DC
2711P-K7C4A8 2711P-T7C4A8 2711P-B7C4A8 ••AC
1000 Model
2711P-K10C4D8 2711P-T10C4D8 2711P-B10C4D8 10.4-in. Color ••DC
512
512
(approx. 79 MB
free user memory)
2711P-K10C4A8 2711P-T10C4A8 2711P-B10C4A8 ••AC
1250 Model
2711P-K12C4D8 2711P-T12C4D8 2711P-B12C4D8 12.1-in. Color ••DC
512
512
(approx. 79 MB
free user memory)
– 2711P-T12C4D8K – ••DC
2711P-K12C4A8 2711P-T12C4A8 2711P-B12C4A8 ••AC
1500 Model
2711P-K15C4D8 2711P-T15C4D8 2711P-B15C4D8 15-in. Color ••DC
512
512
(approx. 79 MB
free user memory)
2711P-K15C4A8 2711P-T15C4A8 2711P-B15C4A8 ••AC
(1) The logic module supports FactoryTalk View Machine Edition software, version 6.0 or later, FactoryTalk ViewPoint software version 1.2 or later, and the Windows CE 6.0 operating system.
