Allen-Bradley PowerFlex 400 User Manual

2-4 3 Contactor Full Feature Bypass with Disconnect Package (Style B/N)
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Table 2.B Overload Ratings
Drive Rating Overload Rating
Input Voltage kW Hp Trip Class
Adjustment Rating
(Amps)
208V AC – 3-Phase 2.2 3.0 20 3.2 - 16
3.7 5.0 20 5.4 - 27
5.5 7.5 20 9 - 45
7.5 10 20 9 - 45
11 15 20 18 - 90
15 20 20 18 - 90
18.5 25 20 18 - 90
22 30 20 40 - 200
30 40 20 40 - 200
37 50 20 40 - 200
460V AC – 3-Phase 2.2 3.0 20 3.2 - 16
4.0 5.0 20 3.2 - 16
5.5 7.5 20 3.2 - 16
7.5 10 20 5.4 - 27
11 15 20 9 - 45
15 20 20 9 - 45
18.5 25 20 9 - 45
22 30 20 9 - 45
30 40 20 18 - 90
37 50 20 18 - 90
45 60 20 18 - 90
55 75 20 40 - 200
75 100 20 40 - 200
90 125 20 40 - 200
110 150 20 40 - 200
132 200 20 100 - 500
160 250 20 100 - 500
200 300 20 100 - 500
250 350 20 100 - 500

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
